DPT-11XDIFFERENTIAL AIR PRESSURE TRANSMITTER DPT-11X
The DPT-11X series differential pressure transmitters are used for measuring low pressure of air and non-combustible gases in order to monitor and control building automation, HVAC and cleanroom systems.
| Usage area | Air |
| Pressure Range | Adjustable (each sensor contains 10 ranges) |
| ±100 Pa / ±1,000 Pa / ±10,000 Pa | |
| 0~100 Pa / 0~1,000 Pa / 0~10,000 Pa | |
| Callibration | Manual with push button or |
| Auto zero calibration when power on | |
| Power Source | 24V AC/DC |
| Output Signal | 0~10V DC / 4~20mA |
| Operating Temp. | 0 ~ 60°C |
| Protection | ABS industrial plastic housing, IP65 |
| Dimensions | 104X90X45mm |
| Installation | Surface mounting |
| Accessories | Duct fixing kit is included |
| Warranty | 2 years |
| Certificates | CE and ISO9001 |
| Country of Origin | People Republic of China (PRC) |
